Niagara Pressure Leaf Filters
Overview
LOREEK Niagara Pressure Leaf Filters are also called plate closed filter.It adopts fully closed deign and pipes connection. This can meet all kind of environmental protection policies and protect the workers. It belongs to one kind of high precision filtration equipment. Up to now, it has been used in chemical, food, mining and many industries.
Our Niagara Pressure Leaf Filters adopt practical stainless steel filter element, which is not easy to deform, corrosion, blockage and large flux. Its welding seam is uniform and smooth, beautiful appearance and convenient maintenance. A distributed flow separation system is installed to make the flow velocity in the barrel uniform and the filtration more precise. It has anti-corrosion buckle, corrosion resistance and long service life.
Main Structure
The kind of vertical leaf filter consists of filter housing, filter leaves, cover lifting device and discharging device. The leaf is made of layers of stainless steel wire screens, then installed on the central filtrate collecting tube, so it's convenient to discharge and clean.
Products Parameters:
1. Working pressure:0.1-0.49Mpa
2. Design temperature:≤150°c
3. Vibrator air pressure:0.45-0.6 Mpa
4. Max. working pressure:0.6Mpa
5. Vibration frequency:3000-4500 times/minute
6. Liquid content in slag: ≤0.5%
Our leaf filter mainly has below filter area: 4 square meters,8 square meters, 10 square meters, 12 square meters,15 square meters, 20 square meters, 30 square meters,40 square meters,50 square meters, 60 square meters,80 square meters.
Products Features of our pressure leaf filter
Model | Filter area | Diameter | Cake Volume | Capacity(t/h) | Height | ||
Oil | Resin | Drink | |||||
VPLF-2 | 2Sq.meter | 400mm | 30L | 0.4-0.6 | 1-1.5 | 1-3 | 1600mm |
VPLF-4 | 4Sq.meter | 550mm | 60L | 0.5-1.2 | 2-3 | 2-5 | 1950mm |
VPLF -7 | 7Sq.meter | 650mm | 105L | 1-1.8 | 3-6 | 4-7 | 2150mm |
VPLF -10 | 10Sq.meter | 800mm | 150L | 1.6-3 | 5-8 | 6-9 | 2300mm |
VPLF -15 | 15Sq.meter | 900mm | 300L | 3-5 | 7-12 | 10-13 | 2400mm |
VPLF -20 | 20Sq.meter | 1100mm | 400L | 4-6 | 9-15 | 12-17 | 2500mm |
VPLF -30 | 30Sq.meter | 1200mm | 600L | 6-8 | 14-23 | 19-25 | 2600mm |
VPLF -40 | 40Sq.meter | 1300mm | 800L | 8-11 | 21-34 | 30-38 | 3000mm |
VPLF -50 | 50Sq.meter | 1400mm | 1040L | 10-15 | 27-45 | 42-51 | 3300mm |
VPLF -60 | 60Sq.meter | 1500mm | 1200L | 11-17 | 36-60 | 56-68 | 3500mm |
VPLF -80 | 80Sq.meter | 1600mm | 1600L | 13-21 | 40-68 | 64-78 | 3800mm |
About LOREEK
LOREEK owns full series production qualifications and over 30 years manufacturing experience in the filtration and separation equipment industry. It is sure that our products has first-class level in China. Our aim is to build LOREEK brand in the world market and win some percentage in the world market. Welcome to contact us and discuss.
Packaging &Transportation Arrangements:
