Self-cleaning Pressure Leaf Filter
Self-cleaning pressure leaf filter consists of filter housing, inner filter leaves, cover lifting device and automatic discharging device. Compare with traditional plate and frame filter press, the automatic cake discharging of pressure leaf filter can be realized by electric or pneumatic vibration. Therefore, workers don’t need to clean the filter plates by hands. It can realize automation and save much labor cost.
The models of pressure leaf filter is determined by filter area. Now we mainly have below models: 4 square meters,8 square meters, 10 square meters, 12 square meters,15 square meters, 20 square meters, 30 square meters,40 square meters,50 square meters, 60 square meters,80 square meters.
Model | Filter area | Diameter | Cake Volume | Capacity(t/h) | Height | ||
Oil | Resin | Drink | |||||
VPLF-2 | 2Sq.meter | 400mm | 30L | 0.4-0.6 | 1-1.5 | 1-3 | 1600mm |
VPLF-4 | 4Sq.meter | 550mm | 60L | 0.5-1.2 | 2-3 | 2-5 | 1950mm |
VPLF -7 | 7Sq.meter | 650mm | 105L | 1-1.8 | 3-6 | 4-7 | 2150mm |
VPLF -10 | 10Sq.meter | 800mm | 150L | 1.6-3 | 5-8 | 6-9 | 2300mm |
VPLF -15 | 15Sq.meter | 900mm | 300L | 3-5 | 7-12 | 10-13 | 2400mm |
VPLF -20 | 20Sq.meter | 1100mm | 400L | 4-6 | 9-15 | 12-17 | 2500mm |
VPLF -30 | 30Sq.meter | 1200mm | 600L | 6-8 | 14-23 | 19-25 | 2600mm |
VPLF -40 | 40Sq.meter | 1300mm | 800L | 8-11 | 21-34 | 30-38 | 3000mm |
VPLF -50 | 50Sq.meter | 1400mm | 1040L | 10-15 | 27-45 | 42-51 | 3300mm |
VPLF -60 | 60Sq.meter | 1500mm | 1200L | 11-17 | 36-60 | 56-68 | 3500mm |
VPLF -80 | 80Sq.meter | 1600mm | 1600L | 13-21 | 40-68 | 64-78 | 3800mm |
Products Features of our pressure leaf filter
1. No need filter cloth or filter paper, greatly saving the cost filtration elements.
2. Fully closed operation, environmental protection, no material loss.
3. Vibration cake discharging, saving labor cost
4. Fully stainless steel design is available. Food grade standards.
5. Well replace plate and frame filter, which is the preferred equipment in filtration industry.
Filter Elements Construction:
The main filter elements of vertical leaf filter is inner filter leaves. Each filter leaf is constructed by 5 layer filter mesh(2 layers filter mesh, 2 layer support mesh and middle support frame). Surely we support 7 layers' construction. The mesh size and filtration precision is determined by the materials that need to be treated.
Application
1. Petrochemical Industry: polyether, diesel oil, lubricating oil, white oil, transformer oil
2. Mineral oil and base oil: dibutyl ester, dioctyl ester
3. Oil: crude oil, bleached oil, gasified oil, winterized oil, etc
4. Food: gelatin, salad oil, starch, sugar juice, monosodium glutamate, milk, etc
5. Pharmaceutical: hydrogen peroxide, vitamin C, glycerin, etc
6. Coatings: varnish, resin paint, real paint, 685 varnish, etc
About LOREEK
Loreek Machinery locates in the central area of China. The local industry bases is very strong and the labor cost is low. Therefore, we can handover quality machines based on lower sales price. We are near Qingdao/Shanghai etc.. sea port. It is easy to deliver goods to the foreign markets.
Focusing on first-class filtration equipment, committed to first-class product quality, LOREEK aims to become an internationally renowned brand of filtration equipment.
Welcome to contact and visit us for business negotiation and technical cooperation!
Packaging &Transportation Arrangements:
For small equipment, we will arrange LCL shipment and wooden cases packaging. For big machines, we will arrange film packaging & FCL shipment.
