Ts Good Quality &Good Price/High Frequency/Double Engine Linear/Coal Slime/Sand/Dewatering Vibration Screen for Gold/Coal/Ore Mining

We meet the diversified and personalized needs of our customers and continue to lead the development of the Fully Automatic Filter Press, Sulphur Filtration Horizontal Pressure Leaf Filter, Vibrating Filter industry. Our company takes the good faith as the foundation, wins the service tenet by the quality, welcome the new old customer to come the person to discuss the business. We take the maximization of corporate benefits as the core, and fully implement the strategy of high point and internationalization. We uphold the principles of honesty and law-abiding, sincere dedication, and continuous pioneering and enterprising, and continue to commit ourselves to making due contributions to local economic construction. We generally imagine your success is our business enterprise!

Products Introduction

Screening sieve: PU screening sieve

Sieve thickness:45mm

Special structure: bending bottom side body plates, no watering leaking

Optional benifits: water box

Working principle:

Dewatering vibrating screen adopts dual-motor self-synchronization technology. The motors coordinate with universal eccentric and adjustable amplitude vibrator. When the two motors start to work, the vibrators move reversely at the same time. The centrifugal force is generated by the eccentric blocks superpose themselves and form a single direction vibration. The high frequency vibration drives the screen move back and forth in line repeatedly. So the sand will be dehydrated and filtered.

Working Principle

Dewatering screen for sand adopts the double motor self-synchronous technology, universal eccentric block and adjustable amplitude vibrator. The two unconnected vibrator perform synchronous reverse operation, the centrifugal force produced by two groups of eccentric mass will be superimposed along the direction of vibration, and reverse eliminated, so as to form a single excitation force along the direction of the vibration, which make the sieve box act as a straight line.

Products Features

1. the high frequency slime dewatering screen mainly consists of screen box, vibration exciter, support system and motor. The screen is installed horizontally, and the screen is installed at a negative angle of step shape (-4 degrees), so as to ensure the effect of forced dewatering.

2. after the water of the fine coal screen and the concentration of centrifugal liquid, the slime shall be dehydrated and recovered by the slime screen. Under high frequency vibration, no J can remove water from coal slime, but also a large amount of fine slime with high ash content (through screening test, it can reduce ash for every J slime of 0.5-0.074mm) The slime after dewatering and desilting can be directly mixed with refined coal.

3. when the coarse particle slime is fed into flotation, it can be recovered in advance by fine coal slime screen to reduce the flotation load, avoid flotation roughing, reduce the dosage of medicine and improve flotation.

4. the coal preparation plant that uses filter press to recover coal slime and increase the sludge dewatering screen recovery system can reduce the load and reduce the consumption of filter cloth, and reduce the production cost and improve economic benefits.

5. small power coal preparation plant adopts a coal slime recovery system composed of coal slime dewatering screen, cyclone and arc screen, which is an economical and practical choice.

Technical parameter

Application area:

We have rich experience and many cases in this industry. Up to now, our machines has exported to more than 40 countries. You can be assured to cooperate with us.

How to choose one suitable model ?

We will offer you exact quotation asap after you provide the following questions.

1. Input material : _____;

2. Sieve mesh sizes:______ mesh or _____mm.

3. Flow Rate: ________L/h.

4. Screen layer:_______(1-5 layers for options)

5.Solid-liquid ratio?

About LOREEK

Zhengzhou Loreek Machinery Equipment Co.,Ltd. is the professional manufacturer of filtration and separation equipment in China. Every year, we sold more than 5000 sets equipment home and abroad.

Excellent products is our brand; Attentive service is our work; Professional technique is our core.

Loreek Products is your excellent Option.

Packaging and Logistics arrangements

We will arrange wooden box for small machines and arrange plastic film for big machines ready for container shipment.

Service is the foundation of enterprise survival. We not only provide professional and excellent Ts Good Quality &Good Price/High Frequency/Double Engine Linear/Coal Slime/Sand/Dewatering Vibration Screen for Gold/Coal/Ore Mining, but also establish a perfect after-sales service system to provide technical support and consulting services for our customers. Employees can feel self-respect and recognition in their work, and share the same fate with the development of the company. Welcome to call us for inquiries and negotiations, we have a professional team of technicians to provide a full range of technical guidance and services.
